FMO 101
Flow meter for 0.02 - 0.44 GPM (0.09 - 1.67 l/min)
![Branch: Industry Branch: Industry](files/flux-pumps/stories/flux-de/products/industry-icons/ind_industry.png)
![Branch: Surface technology Branch: Surface technology](files/flux-pumps/stories/flux-de/products/industry-icons/ind_surface-technology.png)
![Branch: Petrochemistry Branch: Petrochemistry](files/flux-pumps/stories/flux-de/products/industry-icons/ind_petrochemistry.png)
![Branch: Agriculture Branch: Agriculture](files/flux-pumps/stories/flux-de/products/industry-icons/ind_agriculture.png)
![Branch: Water treatment Branch: Water treatment](files/flux-pumps/stories/flux-de/products/industry-icons/ind_water-preparation.png)
![Branch: Paints and lacquers Branch: Paints and lacquers](files/flux-pumps/stories/flux-de/products/industry-icons/ind_dye-lacquer.png)
![Branch: Chemistry Branch: Chemistry](files/flux-pumps/stories/flux-de/products/industry-icons/ind_chemical.png)
The FMO oval rotor flow meter is suitable for use with thin to highly viscous, clean liquids. With the FLUXTRONIC®, batching and dosing a wide variety of liquids can be performed with a high degree of accuracy and safety. In automatic mode it is possible to batch and meter. For example, when paired with the FAE hand nozzle and FSV amplifier, one-touch batching with automatic shutoff is possible.
Product attributes
- Oval rotor design
- For thin to highly viscous pure media
- Available with integrated evaluation unit FLUXTRONIC® or as impulse version
- For the use in piping systems
- High accuracy and repeat accuracy
- Signal can be forwarded to FLUXTRONIC® or another external control as e.g. PLC
- Can be displayed in liter, gallons or kilogram
- Semi-automatic filling with a switching amplifier possible
- Can be used for ex-applications in Zone 1
- Batch operation possible (automatic mode)
- Very precise dosing possible
- High resistance
- Wide range of viscosities can be covered
- Low pressure loss
- Versions also available for hazardous areas
- Can also be used for pulsating volume flows
- FOOD version conform EC 1935/2004 and FDA CFR 21 for contact with food available
Technical Data
- Flow Rate: 0.02 - 0.44 GPM (0.09 - 1.67 l/min)
- Measurement error of the flow rate at < 5 cPs: +/- 2.5%
- Measurement error of the flow rate at > 5 cPs: +/- 1%
- Operating pressure max: PVDF: 145 PSI S: 1450 PSI
- Viscosity max: 1000 cPs
- Housing Materials: Polyvinylidene flouride, Stainless steel
- Fluids: Acids, Alkalis, Petroleum products, Highly flammable media, Solvents, Fuels
- Related videos
- Related literature
- Sample fluids
- Oils
- gasoline
- solvents
- not self-lubricating media
